Features
Transform substrates. Transform your business.
- The HP Latex R530 is the only compact all-in-one hybrid printer that handles both rigid substrates and roll media in a single machine — without sacrificing quality or productivity.
- Direct-to-rigid printing eliminates the print-and-mount process, saving an average of 250 m² of self-adhesive vinyl per month and dramatically reducing material costs and waste.
- HP High Control Belt System with smart vacuum enables accurate media advance and easy loading for both flatbed and roll-to-roll jobs.
- Spindle-less printing and an intuitive touchscreen allow fast, seamless transitions between rigid and flexible loading — no specialist operator required.
- Compact footprint on single-phase power: requires less operational space than any conventional 4×8 ft flatbed printer, making it accessible for growing print shops.
- Remote production control with HP PrintOS Production HUB² — monitor and manage your workflow from anywhere, in real time.
Achieve stunning colours and preserve media look and feel
- HP Pixel Control technology maintains your media's surface texture and look and feel — delivering premium, consistent colour quality across both rigid boards and flexible roll substrates.
- Wide-gamut HP Latex Inks produce solid colours and elevated gradients that stand out — from high-impact outdoor signage to premium retail POS displays.
- One unified ink system covers every application: indoor and outdoor signage, vehicle graphics, wall coverings, backlit, thermoforming, soft signage, and short-run customised packaging — explore all five high-margin R530 applications in our full guide.
- UL ECOLOGO® Certified⁸, water-based HP Latex Inks produce odourless prints⁷ — safe for installation in occupied spaces, retail environments, and food-adjacent settings without ventilation requirements.
- Help reduce running costs with large-format 5-litre HP Latex Ink cartridges — fewer changeovers, lower cost per print.
Expand your offering with the glossiest, high-opacity white
- The HP Latex R530 delivers the glossiest, high-opacity white in its class — with outstanding resistance to yellowing across a wide range of rigid and flexible media types.
- No waste between white jobs: removable HP Thermal Inkjet printheads are stored in an offline rotating chamber when not printing white, eliminating dry-out and purging waste.
- Automatic white ink recirculation and printhead cleaning mean you are always ready to print white — no manual intervention, no production delays.
- High-opacity white unlocks high-margin applications including backlit graphics, window graphics on transparent substrates, printing on dark rigid panels, and thermoformed 3D decoration.
Increase your productivity with smart printing
- Print up to 334 ft²/h (31 m²/h) in Draft mode — or up to 28 outdoor boards per hour⁵ with the belt system and smart vacuum in high-speed quality mode.
- Drive peak production with multi-board printing⁶, assisted loading, and advanced job queuing — keep the machine running through high-demand periods with minimal operator intervention.
- Maximise uptime with automatic maintenance routines and smart service tools for rapid remote diagnosis and issue resolution.
- Maintain full visibility and control over production throughput, ink consumption, and costs with HP PrintOS software tools.
Lead with sustainability — certified, documented, and differentiated
- Advance your sustainability credentials with HP Sustainability Amplifier software⁵ — a self-assessment, resource, and recognition programme that quantifies your environmental impact reduction.
- Ensure fibre-based media remains recyclable⁴: printing with the HP Latex R530 on evaluated substrates maintains recyclability per PTS-RH 021 Category 2 — verified by TU Darmstadt.
- Create a healthier workspace with odourless, water-based HP Latex Inks — no solvent fumes, no VOC emissions, no ventilation requirements during printing.
- Promote circularity: the HP Latex R530 contains at least 25% recycled plastic⁹ and includes a returnable extended-life¹⁰ maintenance cartridge to reduce consumable waste.
Technical Specifications
| Specification | Detail |
|---|---|
| Print Speed | 334 ft²/h – Draft (4-pass); 258 ft²/h – Fast (6-pass); 167 ft²/h – Standard (12-pass); 124 ft²/h – Quality (16-pass); 99 ft²/h – White Spot (100%) |
| Print Resolution | Up to 1200 × 600 dpi |
| Technology | HP Latex Printing Technologies — water-based HP Latex Inks |
| Ink Cartridges | 9 cartridges: Black, Cyan, Light Cyan, Magenta, Light Magenta, Yellow, White, HP Latex Optimizer, HP Latex Overcoat — 5-litre cartridge size |
| Printheads | 10 (2× Cyan/Black, 2× Magenta/Yellow, 2× Light Cyan/Light Magenta, 2× White, 1× HP Latex Optimizer, 1× HP Latex Overcoat) |
| Maximum Media Width | 64 in (162.5 cm) |
| Maximum Substrate Thickness | Up to 2 in (50 mm) |
| Media Handling | Flatbed, sheet feed, roll feed; HP High Control Belt System with smart vacuum for accurate media advance |
| Rigid Substrates | Paper foamboard, plastic foamboard, PVC foam, plastic corrugated, acrylic, polycarbonate, polystyrene, compressed cardboard, wood, glass, corrugated board, honeycomb board, aluminium composite panel, ceramic |
| Roll Substrates | PVC banner, self-adhesive vinyl, coated paper, PE, and more |
| Applications | Indoor & outdoor signage, backlit, thermoforming, wall coverings, window decoration, fleet graphics, vehicle wraps & decals, soft signage (frontlit/backlit), corrugated POS displays, short-run customised packaging, prototyping |
| Connectivity | Gigabit Ethernet (1000Base-T) |
| Power Requirements | 200–240 V, 50/60 Hz (±3 Hz); single-phase; 16 A input; 2,000 W peak power (per power cord) |
| Dimensions (W × D × H) | 103.5 × 68.1 × 60.9 in (without tables); 103.5 × 126 × 60.9 in (with tables) |
| Product Weight | 1,455 lb (660 kg) without tables |
| Operating Temperature | 59–86°F (15–30°C) |
| Acoustics | 65 dB(A) sound pressure (operating) |
| Ink Certification | UL ECOLOGO® Certified (HP Latex Inks) |
| Safety Compliance | IEC 62368-1; USA & Canada (CSA listed); EU (MD compliant, EN12100, EN60204-1, EN1010-1) |
Further Reading
- HP Latex R530: One Printer, Rigid and Flexible — Applications & Technology Guide — A full breakdown of the five high-margin market segments the R530 opens up, including retail POS, indoor & outdoor signage, window graphics, and interior décor.
² HP PrintOS Production HUB premium features require HP Professional Print Service Plus Plan. Compatible with HP Latex printers and HP Stitch Printer series.
³ Compared to traditional print-and-mount workflows; savings based on internal HP estimates averaging 250 m² self-adhesive vinyl saved per month.
⁴ Recyclability evaluation conducted by TU Darmstadt PMV per PTS-RH 021 Category 2. Applies to printing on 3A DISPA Plus, Neenah ImageMax, Reboard Honeycomb Brown, Kaemmerer Chantaffiche 200 JE, and HP Premium Poster Paper.
⁵ HP Sustainability Amplifier helps customers reduce environmental impact through self-assessment, resources, and recognition. Programme availability may vary by region.
⁶ Multi-board printing and speed of 28 boards/hr based on internal HP testing. Actual performance varies by substrate, mode, and job configuration.
⁷ Odourless performance is media-dependent. Some media types may affect print odour profile.
⁸ UL ECOLOGO® Certified HP Latex Inks meet stringent human health and environmental criteria. See www.ul.com/EL and www.ul.com/gg for current certifications.
⁹ Based on product weight including packaging materials assessed during product design.
¹⁰ Extended-life maintenance cartridge is returnable to HP for responsible recycling.
Manufacturer information: HP Latex R530 printer (HP Malaysia)
